7 steps to optimize slow dashboards • Google Data Studio


Wojtek Andrzejczak
7 steps to optimize slow dashboards • Google...

Learn how to optimize slow dashboards and reduce loading time while interacting with sorting and filtering your data.

Before we start

The building dashboard in Google Data Studio is straightforward and quick. But even with a simple dashboard using Google Analytics connector, we might notice that loading time for a result takes a relatively long time. And we did not event start joining data sources or creating custom calculation fields that have a significant impact on performance.

Why are slow dashboards a problem?

From a technical point of view, the server is under massive memory and CPU usage. More users use dashboard then slower overall performance might become.

From the development point of view, the longer we wait for data to load, then more time we spent on development and testing. Time is money.

From the user point of view, the longer the user waits for data to load, then less happy he is to use the dashboard.

When is dashboard loading time too much?

There is no direct rule which defines that. But from my experience, if the loading time takes more then 3 seconds, then many users might see this as slow.

Why more than 3 seconds? There are many studies regarding page speed and related to its user behaviors. And since Google Data Studio dashboards are also loading inside of the browser, this might be taken as expected behavior. Impact of the page speed I’ve described in this article.

Of course, the advanced and very complicated dashboard might take more time due to the complexity, but those are exceptional examples.

How to optimize slow dashboards?

In our example, I’ve used a simple Google Analytics connector to display very basic data on the dashboard. Similar logic can be applied to Google DV360 and Google Ads connectors.

Fix too many fields in the data sources

The reason why I’ve selected Google Analytics is that by default, it pulls all atomic event data (page visit, transaction, custom events) with all available dimensions and metrics.

As you can see, we have 519 all available fields. And every time you pull data, Google Data Studio is pulling everything from your defined time range. It is many data. Easly 90% of those fields you don’t need to use in your dashboard.

Google Data Studio / Google Analytics Data Source
Google Data Studio / Google Analytics Data Source

Fix too complicated data sources

Imagine you display aggregated daily base page views. The problem is that the Google Analytics connector sends to Google Data Studio atomic events. So Google Data Studio must count the sum of page views for each day. And if you have 1mln page views per day, Data Studio needs to aggregate 14mln page views from the last 14 days to display 14 rows and recalculate it every time you apply or change filter.

This aggregation should be done in the data source, not on the dashboard.

Example dashboard

I’ve created a simple dashboard where we aggregate visits by continent, country, and we compare Page Visits with Bounce Rate from the last 4 months.

We use 4 out of 519 fields in the data source.

Google Data Studio / Slow dashboards to optimize
Google Data Studio / Slow dashboards to optimize

Solution

Let’s discuss what we could do to make things right. Steps bellow described a universal approach that can be applied to other data source connectors that solve slow dashboards problems in the future.

Create a new data source extract

Since we already have a Google Analytics connector that pulls all available data, we need to create an extract that will use our previously created connector but take only those dimensions and metrics we need for our dashboard.

Under Data sources, we need to find a connector called “Extracted Data”.

Google Data Studio / Data sources / Extract Data
Google Data Studio / Data sources / Extract Data

Include only the fields you want to use

Inside of the extract, we define the original data source, which, in our case, is previously created Google Analytics data source.

From the available fields list, we select only those fields we need to use in the dashboard.

We can also define a filter, exclude unwanted data, or focus only on a small part of the data.

Extract Data / Optimize Dashboard fields
Extract Data / Optimize Dashboard fields

Apply filters from the dashboard

As an example filter, we exclude all Analytics events where the custom events were not empty. Why? I don’t know, this is just an example : – )

Extract Data / Optimize Dashboard filters
Extract Data / Optimize Dashboard filters

Define time range

It is an important part. Extract, by definition, should be small and quick.

If you define date range to last 14 days, the extract will contain cached data from the last 14 days. And access to this data will be quick. But, if on the dashboard you allow the user to change the date and he will select the date range “last 30 days”. Our extract will do not contain this data, so he will request those data from the original data source. And this will take a much more extended period.

Always put in the extract a bit more time overhead for the data.

Extract Data / Optimize Dashboard time range
Extract Data / Optimize Dashboard time range

Enable auto-update

If we want our extract to auto-update as soon as the original data source receives data, you need to enable this function, which is disabled by default.

Extract Data / Auto-update data in extract
Extract Data / Auto-update data in extract

Replace data source

When new data extract is ready, in the dashboard, we can now replace data sources from the original one to the new one.

Google Analytics dashboard / Replace data source to extract
Google Analytics dashboard / Replace data source to extract

Fix missing fields problems

It might happen that you will see an error saying that some fields are missing and incomplete configuration.

Since we’ve restricted fields list and moved data filters from the dashboard to the extract, we must remove the previously created filters from the dashboard.

Google Analytics dashboard / Remove filters
Google Analytics dashboard / Remove filters

Result

After removing the filter from the dashboard, data will show instantly.

Instead of 519 available fields, we see just 4. Even if there is not that much data, we can notice that loading and switching between filters are noticeably quicker.

Google Analytics dashboard / Finished optimized slow dashboards
Google Analytics dashboard / Finished optimized slow dashboards

Summary

I’ve applied a similar approach to one of our client’s dashboards, where we need to make custom events and transaction calculations. After applying extract interaction, the time has changed from 10-20s to 1-2s. And this change is significant.

If you have any questions, please leave a comment, or contact me directly via LinkedIn 🙂
